Dati tecnici | ||||||||
Fibra Num. | Diametro esterno (mm) | Peso (kg/km) | Min.Radius di piegatura ((mm) | Tensione (N) | Carico di collisione (N/100 mm) | |||
Staticità | Dinamica | A breve termine | A lungo termine | A breve termine | A lungo termine | |||
2-24 | 12.6 | 185 | 12.5 volte l'overdose. | 25 volte O.D. | 3000 | 1000 | 3000 | 1000 |
26-36 | 12.9 | 195 | ||||||
38-60 | 13.4 | 200 | ||||||
62-72 | 13.9 | 230 | ||||||
74-96 | 15.5 | 275 | ||||||
98-120 | 17 | 320 | ||||||
122-144 | 18.4 | 365 | ||||||
146-216 | 18.9 | 385 | ||||||
218-240 | 22.1 | 495 | ||||||
242-288 | 24.3 | 580 |
